Model NO.
1s
Delivery:
FOB
Quantity:
  • Usage:Motorcycle / Scooter
  • Sealed Type:Sealed
  • Maintenance Type:Free
  • Certification:ce
  • Brand Name:QNBBM
  • Model Number:1s
  • Weight:0.1KG
  • Place of Origin:CN;GUA
  • Size:85*40*25MM
  • Products Name::1S Battery Equalizer Single Cell Li-ion LiFePO4 LTO NCM
  • Key word::Lithium battery equalizer
  • Battery method::Energy transfer/Dynamic
  • Battery type::Lifepo4,LiMnO4,AGM,GELL,Flooded battery and so on
  • Battery Capacity::unlimited
  • Power consumption::lower than 50mw
  • Balance current::6A
  • Work efficiency::over 94%
  • BMS limited::can work with BMS or can work independently

1S Lithium Battery Equalizer Li-ion LiFePO4 LTO NCM Polymer 18650 DIY Active BMS Battery Balancer:



QQ20181002140335







Related products:



6_.jpgTC12_.jpg10_.jpgGBS 20AH_.jpg





Parameter of Deligreen Battery Equalizer:


 Diagram.jpgFeatures of module.jpgFeatures2.jpg

 Features of Deligreen Battery Equalizer:



Online Working      To blance during charge,discharge,storage
Dynamic equalizing:      To prevent batteries out of balancing all the time
Engery transfer:      Transfer energy from higher voltage cell to lower ones
Maintenance and recovery:      To Keep normal batteries at a good condiction ,recover the  backwards ones
Sharing capacity:      Let the power  flow from one cell to another and share them among the cells
Simple installation:      Connect the balancer together then connect to battery+ and battery-
Independent:      No affect to battery pack wiring,no impact to charging and discharging





FAQ



 Why you need a batery balancing systerm


The individual cells in a battery pack are rarely an exact duplicate of all the cells in the battery pack.

In actual practice, when a pack of batteries reaches a specified charge cutoff voltage then the charger will shut off. If one cell in a pack reaches that voltage before other cells reach a full charge it will cause the charger to shut off - prematurely denying the balance of the pack a full charge.

Conversely when the weakest cell in a pack reaches its discharge cutoff voltage it will show as the discharge point and shut down the pack prematurely - thereby denying the user the balance of energy the other cells have stored.

These battery equalizers prevent this from happening. This yields up to 30% more power and will extend the life of the battery pack.

Benefits:
Quick and easy installation
Keeps your batteries voltage difference within 10mV!
May increase the lifespan of your battery pack by 2-3 times by preventing the batteries from being overcharged or over discharged

Features:
§  High frequency pulse, dynamic battery voltage-amperage balancer
§  Simple wiring and high efficiency
§  Works with all charger amperage and voltage inputs
§  All 1S Single Balancers come with the interconnecting and battery wiring
§  0.5 m/1.5 ft. maximum suggested wire length for all the multiple series balancers. (35m 4S, 5S, 6S, 8S)
§  Idle Current Draw is <50mW
§  Series modules
·Modules may work with 3, 4, 5, 6, or 8 batteries in series (AKA 3S, 4S, 5S, 6S, or 8S)
·Does not come with the wiring to connect to the batteries
Example:
A 144v pack of 48 cells,
20 in the front and 28 in the back
can use 8S+8S+4S in front
and 8S+8S+8S+4S in the back.





Company Information



Patent of the Battery equalizer :

QQ20180809111827





Massive Stocks

Warranty three years

Fast delivery :1-2days

Customized service acceptable



.jpg







User Attention:



Firstly, if your order 1S balancers,we have 20cm wires one the balancers with M8 terminals as default .



If you need other size of terminals and different length of wires,pleae tell us.



If you order balance modules,mo terminals or wires.



Second,The balance power consumption is less than 50mW.



If you don't use the battery for over 2 months,please either disconnet the balancers ,or recharge the battery once a month or once two months. Recharging the batteris occasionally is better for your batteries as well.



Third, we have wiring diagram on the balance modules ,don't make any mistakes,if you are unsure of installation, please contact our sales person,we will be glad to help you

 4S+4S newest 20151229.jpg
