Model NO.
DS-T2P
Delivery:
FOB
Quantity:
  • Place of Origin:CN;JIA
  • Type:Floor Socket
  • Grounding:Standard Grounding
  • Application:Residential / General-Purpose
  • Brand Name:Duosida
  • Model Number:DS-T2P
  • Rated Voltage:220V-250V
  • Rated Current:32A
  • Products Name::Duosida Type 2 iec 62196-2 EV Side Charger Plug 32A
  • Key word::iec 62196-2 ev plug
  • Grounding::Standard Grounding
  • Mechanical life::no-load socket in/pull out >10000 times
  • Operating temperature::-30°C ~ +50°C
  • Case Material::Thermoplastic
  • Certifications::CE, TUV, UL
  • Withstand Voltage::2000V
  • Rated current::16A/32A
  • Application::Automotive

Promotional Duosida Type 2 iec 62196-2  EV Charger Plug 32A with 5meters Three Phase Cable for Vehicle Charging Station:








 Related Products:

KH .jpgTIM20171026172716__.jpg.jpg22_.jpg.jpg.jpg



Specification of Type2 EV Plug:



Insert arrangements and functional definition





Mark

functional definition

1- (L1)

AC power

2- (L2)

AC power

3- (L3)

AC power

4- (N)

Neutra

5- (PE)

PE

6- (CP)

Control confirmation

7- (PP)

Connection confirmation



Model selection and the standard wiring



Model

Number of inserts

Cable Spec.

Remark

DSIEC2e-EV16P

7

5*2.5mm+2*0.5mm2

The length of the cable can be customized

DSIEC2e-EV32P

7

5*6mm+2*0.5mm2



Charging Coupler Interface






Products image of Type2 EV Plug :






Products Certification & Application:
